3Pcs Mini 1A Lithium Battery Charging Board Charger Module USB Interface

Name: 3Pcs Mini 1A Lithium Battery Charging Board Charger Module USB Interface
Brand: Burnett Canada
SKU: C122-1067575
Price: 18.94 CAD
Availability: OutOfStock

$18.94 CAD

Promotion Épuisé

Quantité

3Pcs Mini 1A Lithium Battery Charging Board Charger Module USB InterfaceDescription:Charging method: linear charge 1%Charging current: 1A adjustableCharge accuracy: 1.5%Input voltage: 4.5V-5.5VFull charge voltage: 4.2VCharging indicator: Red charging green full chargeCharging input interface: Mini USBWorking temperature: -10°C to +85°CReverse: NOSize: 25 x 19 x 10mmNote:Ampere meter can only be connected to 5V input end of the module.It is better that the charging current is 37% of the battery capacity. If you charge to the battery of 1000mAH, current of 400 is enough.The connection wire should not be too long.Make sure the connect point is good.If the input voltage is too high, like 5.2V, the current will be less than 1000mA, it is normal. It is protection function, Auto-substract the charging current to avoid burn damage to chip.Input reverse has no effect on the chip, but the output (battery terminals) reverse will burn chips.Applications:This module is used for single-or multi-section parallel lithium lithium rechargeable battery, charging from the USB port to take power.Package included:3 x 1A lithium battery charging module
